Connection for
Terminal assignment
Voltage supply
Type 707050
R
B
= (U
b
- 11 V)/22 mA
DC 11 to 35 V
Current output
R
B
= Load resistance
4 to 20 mA
U
b
= Voltage supply
Analog inputs
RTD temperature probe
R
L
≤
11
Ω
2-wire circuit
R
L
= Lead resistance per wire
RTD temperature probe
R
L
≤
11
Ω
3-wire circuit (3W)
R
L
= Lead resistance per wire
RTD temperature probe
R
L
≤
11
Ω
4-wire circuit (4W)
R
L
= Lead resistance per wire
Thermocouple
Resistor/potentiometer
R
L
≤
11
Ω
2-wire circuit
R
L
= Lead resistance per wire
Resistor/potentiometer
R
L
≤
11
Ω
3-wire circuit (3W)
R
L
= Lead resistance per wire
Resistor/potentiometer
R
L
≤
11
Ω
4-wire circuit (4W)
R
L
= Lead resistance per wire
Resistance transmitter
E = End
S = Slider
A = Start
Voltage 0 to 1 V
2
1
+
–
4
5
6
3
J
4
5
6
3
J
4
5
6
3
J
+
–
4
5
6
3
4
5
6
3
4
5
6
3
4
5
6
3
E
S
A
4
5
6
3
+
4
5
6
3
–
