background image

2012-06-04/00576949

Data Sheet 707050

Page 3/12

JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14

36039 Fulda, Germany

Postal address:

36035 Fulda, Germany

Phone:

+49 661 6003-0

Fax:

+49 661 6003-607

E-mail:

[email protected]

Internet:

www.jumo.net

JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax:

+44 1279 635262

E-mail:

[email protected]

Internet: www.jumo.co.uk

JUMO Process Control, Inc.
8 Technology Boulevard
Canastota, NY 13032, USA
Phone: 315-697-5866

1-800-554-JUMO

Fax:

315-697-5867

E-mail:

[email protected]

Internet: www.jumo.us

Thermocouples

Resistance transmitter and resistor/potentiometer

Direct current

Designation

Type

Standard

ITS

Measuring range
in °C

Measuring accuracy

a

a

The accuracy values refer to the complete measuring range.

Min.

Max.

Pt13Rh-Pt

R

IEC 584-1

ITS-90

-50

1768

± 0.15 % from +50 °C

Pt10Rh-Pt

S

IEC 584-1

ITS-90

-50

1768

± 0.15 % from +20 °C

Pt30Rh-Pt6Rh

B

IEC 584-1

ITS-90

0

1820

± 0.15 % from +400 °C

Fe-CuNi

J

IEC 584-1

ITS-90

-210

1200

± 0.1 % from -100 °C

Cu-CuNi

T

IEC 584-1

ITS-90

-270

400

± 0.1 % from -150 °C

NiCr-CuNi

E

IEC 584-1

ITS-90

-270

1000

± 0.1 % from -80 °C

NiCr-Ni

K

IEC 584-1

ITS-90

-270

1372

± 0.1 % from -80 °C

NiCrSi-NiSi

N

IEC 584-1

ITS-90

-270

1300

± 0.1 % from -80 °C

Fe-CuNi

L

DIN 43710

IPTS-68

-200

900

±

0.1 %

Cu-CuNi

U

DIN 43710

IPTS-68

-200

600

± 0.1 % from -100 °C

Chromel-Copel (Ni9.5Cr-Cu44Ni)

L

GOST R 8.585-2001

ITS-90

-200

800

± 0.1 % from -80 °C

Chromel-Alumel

GOST R 8.585-2001

ITS-90

-270

1372

± 0.1 % from -80 °C

W5Re-W20Re

A1

GOST R 8.585-2001

ITS-90

0

2500

± 0.15 %

W5Re-W26Re

C

ASTM E230/E230M-11

ITS-90

0

2315

± 0.15 %

W3Re-W25Re

D

ASTM E1751/E1751M-09

ITS-90

0

2315

± 0.25 %

PL II (Platinel

b

II)

b

Platinel is a registered trademark of Engelhardt Corp.

ASTM E1751/E1751M-09

ITS-90

0

1395

± 0.15 %

Cold junction

Pt1000 internal or external cold junction; temperature adjustable 0 to 80 °C

Cold junction accuracy

± 1 K

Designation

Measuring range

Measuring accuracy

Resistance transmitter

Up to 10000

Ω

±10

Ω

Resistor/potentiometer

400

Ω

±

400 m

Ω

400

Ω

to

4000

Ω

±

4

Ω

>

4000

Ω

to

10000

Ω

±

10

Ω

Connection type

Resistance transmitter: 3-wire circuit

(A = Start, S = Slider, E = End)

Resistor/potentiometer: 2-wire circuit, 3-wire circuit, and 4-wire circuit

Sensor lead resistance

11

Ω

per line for 2-wire circuit, 3-wire circuit, and 4-wire circuit

Designation

Measuring range

Accuracy

a

a

The accuracy value refers to the complete measuring range.

Input resistance

Input for mV generator

-100 to 1100 mV

±0.05 %

R

E

1 M

Ω
