2012-06-04/00576949

Data Sheet 707050

Page 5/12

JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14

36039 Fulda, Germany

Postal address:

36035 Fulda, Germany

Phone:

+49 661 6003-0

Fax:

+49 661 6003-607

E-mail:

[email protected]

Internet:

www.jumo.net

JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax:

+44 1279 635262

E-mail:

[email protected]

Internet: www.jumo.co.uk

JUMO Process Control, Inc.
8 Technology Boulevard
Canastota, NY 13032, USA
Phone: 315-697-5866

1-800-554-JUMO

Fax:

315-697-5867

E-mail:

[email protected]

Internet: www.jumo.us

Customer-specific linearization

Voltage supply

Environmental influences

Method

Characteristics

Pairs of values

Max. number: 40

Interpolation: linear

Formula

Number of coefficients: 5

Polynomial: 4th order

707050

707051

Voltage supply (U

b

)

DC 11 to 35 V (with reverse voltage protection

a

)

Only for operation in SELV, PELV current circuits according to DIN EN 50178

a

Prerequisite for use of the voltage output of type 707051 is a supply voltage of at least 15 V

Voltage supply error

± 0.01 %/V deviation from 24 V

b

b

All specifications refer to the measuring range end value of 20 mA

707050

707051

Operating temperature range

-40 to +85 °C

-10 to +70 °C

Storage temperature range

-40 to +100 °C

-10 to +70 °C

Temperature influence

RTD temperature probe

±0.005 %/K deviation from 22 °C

a

Resistance transmitter

±0.01 %/K deviation from 22 °C

a

Resistor/potentiometer

±0.01 %/K deviation from 22 °C

a

Thermocouple

±0.005 %/K deviation from 22 °C

a

(plus accuracy of the cold junction)

Direct current

±0.01 %/K deviation from 22 °C

a

Long-term stability

0.1 K/year

b

or

0.05 %/year

c

Resistance to climatic conditions

In terminal head, form B

Rel. humidity

95 %, with condensation

Open assembly

Rel. humidity

95 %, without condensation

On DIN rail

Rel. humidity

95 %, without condensation

Vibration resistance

DIN EN 60068-2-6

Max. 2 g at 10 to 2000 Hz

Max. 2 g at 10 to 55 Hz

DIN EN 60068-2-27

Shock; 10 g/6 ms

Shock; 10 g/6 ms

Germanischer Lloyd

Characteristic line 2

-

Electromagnetic compatibility
(EMC)

According to DIN EN 61326-1

Interference emission

Class B

Interference resistance

Industrial requirements
