2012-06-04/00576949

Data Sheet 707050

Page 2/12

JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14

36039 Fulda, Germany

Postal address:

36035 Fulda, Germany

Phone:

+49 661 6003-0

Fax:

+49 661 6003-607

E-mail:

[email protected]

Internet:

www.jumo.net

JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax:

+44 1279 635262

E-mail:

[email protected]

Internet: www.jumo.co.uk

JUMO Process Control, Inc.
8 Technology Boulevard
Canastota, NY 13032, USA
Phone: 315-697-5866

1-800-554-JUMO

Fax:

315-697-5867

E-mail:

[email protected]

Internet: www.jumo.us

Technical data

Analog input

All analog inputs are equipped with a digital filter of second order (filter constant adjustable from 0 to 10 s) and have a sampling rate of > 2 mea-
surements per second.

RTD temperature probe

Designation

Standard

ITS

Connection type Measuring range

in °C

Measuring accu-
racy

a

a

The accuracy value refers to the complete measuring range.

Min.

Max.

Pt100

IEC 60751:2008

ITS-90

2/3-wire

-100

200

±0.2 K

Pt500

2/3-wire

-200

850

±0.4 K

Pt1000

4-wire

-100

200

±0.1 K

T

K

= 3.85 × 10

-3

1/K

4-wire

-200

850

±0.2 K

Pt100

GOST 6651-2009 A.2

ITS-90

2/3-wire

-100

200

±0.2 K

T

K

= 3.917 × 10

-3

1/K

2/3-wire

-200

850

±0.4 K

4-wire

-100

200

±0.15 K

4-wire

-200

850

±0.25 K

Pt50

2/3-wire

-200

850

±0.5 K

T

K

= 3.91 × 10

-3

1/K

4-wire

-200

850

±0.3 K

Ni100

DIN 43760

IPTS-68 2/3-wire

-60

250

±0.4 K

T

K

= 6.18 × 10

-3

1/K

4-wire

-60

250

±0.2 K

Ni500

2/3-wire

-60

250

±0.4 K

T

K

= 6.18 × 10

-3

1/K

4-wire

-60

250

±0.2 K

Ni1000

2/3-wire

-60

250

±0.4 K

T

K

= 6.18 × 10

-3

1/K

4-wire

-60

250

±0.2 K

Ni 100

GOST 6651-2009 A.5

ITS-90

2/3-wire

-60

180

±0.4 K

T

K

= 6.17 × 10

-3

1/K

4-wire

-60

180

±0.2 K

Cu50

GOST 6651-2009 A.3

ITS-90

2/3-wire

-180

200

±0.5 K

T

K

= 4.28 × 10

-3

1/K

4-wire

-180

200

±0.3 K

Cu100

2/3-wire

-180

200

±0.4 K

T

K

= 4.28 × 10

-3

1/K

4-wire

-180

200

±0.2 K

Connection type

2-wire, 3-wire, or 4-wire circuit

Sensor lead resistance
- For 3/4-wire circuit

11

Ω

per line

- For 2-wire circuit

Measuring resistance +

22

Ω

inner line resistance

Sensor current

< 0.3 mA
