2 Introduction
2.3.2 Required accessories
Choke: L = 0.6mH/I
Nom
= 200A, protection rating IP 20, as per EN 60 529
2.3.3 Further accessories
EMC filter
Semiconductor fuse
2 extra fast semiconductor fuses are installed in the converter, to protect the
IPC in the event of an earth short.
The I
2
t value of the semiconductor fuse must be less than 20000 A
2
s!
Sales No. 70/00434229
Dimensions Connection Tightening torque
for screw terminals Weight Sales No.
Height: 190 mm
Width: 200 x 385 mm Via screw terminals
from 35 to 95 mm
2
max. 15...20 Nm approx.
37kgs 70/00436848
For voltage supply to power section
Nominal voltage,
nominal current
Dimensions
(L x W x H)
Tightening torque
for
screw terminals Weight Permissi
ble
ambient
temperat
ure
Sales
No.
115V/250V/440V
AC,
I
Nom
= 16A
(255 x 60 x 130) mm 0.6 ... 0.8 Nm approx.
4kgs 40°C 70/00399527
115V/250V/440V AC,
I
Nom
= 20A
(289 x 70 x 140) mm 1.5 ... 1.8 Nm approx.
5.5 kgs 40°C 70/00438775
115V/250V/440V
AC,
I
Nom
= 32A
(324 x 90 x 160) mm 1.5 ... 1.8 Nm approx.
9.5kgs 40°C 70/00409831
115V/250V/440V
AC,
I
Nom
= 63A
(380 x 117 x 190) mm 2 ... 2.3 Nm approx.
17kgs 40°C 70/00409990
115V/250V/440V
AC,
I
Nom
= 100A
(445 x 150 x 220) mm 6 ... 8 Nm approx.
26 kgs 40°C 70/00431997
For voltage supply to the control section
115V/250V AC,
I
Nom
= 1A
80 x 45 x 30 mm - approx.
120g 40°C 70/00413620
