IGBT Power Converter 200A [Patent No. EP1 126 591 B1] 02.08 47
6 Technical data
6.5 Choke data
6.6 EMC filter
Type Dimensions Connection
cross
section Tightening torque
for screw terminals Weight Sales No.
L = 0.6 mH / I
N
=
200A protection
rating IP 20 as per
EN 60529
Height: 190 mm
Width: 200 x 385mm
35...95 mm
2 max. 15...20 Nm approx.
37 kgs 70/00436848
For voltage supply to power section
Nominal voltage,
Nominal current Dimensions
(length x width x
height) Connection
cross-section Tightening torque
for
screw terminals
Weight Permissible
ambient
temperature Sales
No.
115V/250V/440V AC,
I
Nom
= 16A
(255 x 60 x 130) mm 0.25...4 mm 2 0.6 ... 0.8 Nm approx. 4
kgs 40°C 70/00399527
115V/250V/440V AC,
I
Nom
= 20A
(289 x 70 x 140) mm 0.5...10 mm 2 1.5 ... 1.8 Nm approx. 5.5
kgs 40°C 70/00438775
115V/250V/440V AC,
I
Nom
= 32A
(324 x 90 x 160) mm 0.5...10 mm 2 1.5 ... 1.8 Nm approx. 9.5
kgs 40°C 70/00409831
115V/250V/440V AC,
I
Nom
= 63A
(380 x 117 x 190) mm 0.5...16 mm
2
2 ... 2.3 Nm approx. 17
kgs 40°C 70/00409990
115V/250V/440V AC,
I
Nom
= 100A
(445 x 150 x 220) mm 10...50 mm
2
6 ... 8 Nm approx. 26
kgs 40°C 70/00431997
For voltage supply to the control section
115V/250V AC,
I
Nom
= 1A
(80 x 45 x 30) mm via
tab connector
6.3 x 0.8mm
- approx. 120
g 40°C 70/00413620
