JULABO F38-ME Beer Forcing Test Refrigerated/Heating Circulating Bath User Manual
Page 16
Operating controls and functional elements
16
4.2. Cooling
Machine
Front view
Rear view
1b
Mains power switch, illuminated for cooling machine
15a
15b
Socket: control cable of JULABO refrigerated circulator
18b
Mains fuses for cooling machine, T10A, D5 x 20 mm
20a
20b
Mains power cable with plug for circulator
Mains power cable with plug cooling machine
21
Built-in mains outlet for connection of circulator
22
Drain tap / Drain port
25
Venting grid, removable
26a
26b
Castor with brake (at the front)
Castor without brake (at the back)
