1 Technical Data
Further technical data → [1], [2], [3].
CDG045D
Supply voltage at the DeviceNet con-
nector
24 V nominal (11 … 25 V)
Power consumption
while being heated
at operating temperature
≤12 W
≤10 W
CDG100D, CDG160D, CDG200D
The temperature controlled CDG100D, CDG160D and CDG200D
gauges with DeviceNet interface require an additional, separate power
supply.
Supply voltage for gauge at D-sub
connector
→ [2], [3]
Supply voltage for DeviceNet trans-
ceiver at micro style connector
24 V nominal (11 … 25 V)
Power consumption <2 W
Fieldbus name DeviceNet
Standard applied → [5]
Communication protocol, data format → [5]
Interface, physical CAN bus
Data rate (adjustable via "RATE"
switch) 125 kBaud
250 kBaud
500 kBaud (default)
"P" (125 kBaud, 250 kBaud, 500 kBaud
programmable via DeviceNet
Node address (MAC ID)
(Adjustable via "ADDRESS", "MSD",
"LSD" switches) 0 … 63
dec
(default = 63
dec
)
"P" (0 … 63 programmable via
DeviceNet)
DeviceNet connector Micro style, 5 pins, male
Cable Shielded, special DeviceNet cable,
5 conductors
(
→ 7 and [4])
Cable length, system wiring according to DeviceNet specifications
(
→ [4], [5])
Supply voltage
DeviceNet interface
