INFICON SKY CDGxxxD (DeviceNet) - Manual (Page 21)

tira51e1 (2009-01) CDGxxxD.cp
21
Attribute
ID
Access rule NV/
V
Name DeviceNet data
type Description of
attribute Semantics of values
21 Set NV Warning trip point
high
INT or specified
by data type Determines the
value above which
a warning condition
will occur [default] = Maximum value for
its data type.
22 Set NV Warning trip point
low
INT or specified
by data type Determines the
value below which
a warning condition
will occur [default] = Minimum value for its
data type.
23 Set NV Warning hysteresis NT or specified
by data type
Determines the
amount by which
the value must
recover to clear a
warning condition [default] = 0
25 Set NV Safe state USINT Specifies the be-
havior for the value
for states other
than execute → "Semantics" section below.
[default] = 0
26 Set NV Safe value INT or specified
by data type The value to be
used for safe state
= safe value → "Semantics" section below.
[default] = 0
32 Get NV Overrange INT or specified
by data type Specifies the hig-
hest valid value The value above which attribute
reading valid is set to invalid.
[default] = maximum allowable
value for the data type
33 Get NV Underrange INT or specified
by data type Specifies the
lowest valid value The value below which attribute
reading valid is set to invalid.
[default] = minimum allowable
value for the data type
93 Get V Sensor
temperature Real The temperature in
Celsius at which
the sensor has
warmed up
94 Get V Sensor warning Struct of byte Bit definitions of
sensor warnings 0 = [default]
→ "Semantics" section below
95 Get V Sensor alarm Struct of byte Bit definitions of
sensor alarms 0 = [default]
→ "Semantics" section below
96 Get V Status extension BYTE Bit-mapped byte
providing additional
status bits of an S-
Analog sensor
instance. 0 = [default]
→ "Semantics" section below
99 Get NV Subclass UINT Identifies a subset
of additional in-
stance attributes,
services and be-
haviors. 3 = Capacitance Manometer
100 Set NV Offset vendor
specific
INT or specified
by data type Customer specified
offset which will be
added to the offset-
A value from zero
adjust service
101 Set NV Filter USINT 0 = Dynamic [default]
1 = Fast
2 = Slow
