INFICON SKY CDGxxxD (DeviceNet) - Manual (Page 29)

tira51e1 (2009-01) CDGxxxD.cp
29
Class Code 09
h
= 09
d
Attribute ID Access
rule
Name DeviceNet
data type Description of attribute
1 Get Revision UINT Revision of this object. Note: All class definitions
are required to include this class attribute.
2 Get Max
instance
UINT Maximum instance number of an object currently
created in this class level of the device.
Attribute
ID
Access
rule
Name DeviceNet
data type Description of attribute Semantics of values
3 Get Value BOOL Output point value. 0 = Off
1 = On (activated)
The discrete output point object provides the following common services:
Service
code
Service name Description of service
0E
h
Get_Attribute_Single Returns the contents of the specified attribute.
4.6 Discrete Output Point
Object
4.6.1 Class Attributes
4.6.2 Instance Attributes of
Instance 1 & 2
4.6.3 Common Services
