12
tira51e1 (2009-01) CDGxxxD.cp
Class Code 01
h
= 01
d
This object provides identification of and general information about the device.
Attribute ID Access rule Name DeviceNet
data type Description of attribute Semantics of values
1 Get Revision UINT Revision of this object.
Note: All class definitions are
required to include this class
attribute. The current value assigned to this
attribute is one (01). If updates that
require an increase in this value are
made, then the value of this attribute
increases by one.
2 Get Max instance UINT Maximum instance number of
an object currently created in
this class level of the device. The largest Instance number of a
created object at this class hierarchy
level.
Attribute ID Access rule NV/
V
Name DeviceNet data type Description of attribute
1 Get NV Vendor ID UINT Manufacturer identification
Value: 633 (INFICON AG) (default)
2 Get NV Device type UINT 1C
h
= Vacuum pressure gauge
3 Get NV Product code UINT 14 (default)
4 Get NV Revision STRUCT
5 Get NV Status WORD
6 Get NV Serial number UDINT
7 Get NV Product name SHORT STRING CDG045D, CDG100D, CDG160D,
CDG200D
The products with different product names only differ in the temperature at which
the sensor element is heated up. Different fullscale values of the gauges exist
within the same product name. The product code is always 14.
Service Code Name Description
5 (05
h
) Reset 0 = last installation,
1 = default installation
14 (0E
h
) Get_Attribute_Single
4.2 Identity Object
4.2.1 Class Attributes
4.2.2 Instance Attributes
Services
