41
ID Name Structure Data type Bytes Access Store
14 Atmosphere
gauge Block State
Command REC 2 1_W
2_W
101 Block Type Simple Octet string 4 2_R
The Block Type ID has the value: "01 00 00 00" (octet string).
This service is used for activating the adjustment of the Piezo sensor to the
Capacitance diaphragm sensor via Profibus.
The atmosphere pressure sensor can be adjusted to the internal (vacuum cham-
ber) Capacitance diaphragm sensor.
If you want to adjust the atmosphere pressure sensor to the Capacitance
diaphragm sensor, proceed as follows:
n
Vent the vacuum system to atmospheric pressure
o
Send the "Release User ATM adjust" command
p
Perform the "User ATM adjust command" as specified below.
After this procedure, the atmosphere pressure sensor will give the same pressure
value as the Capacitance diaphragm sensor at atmospheric pressure.
ID Name Structure Data type Bytes Access
14 Atmosphere gauge Block
State Command Record → below 2 1/2_W
Transition Command Simple Unsigned8 1
Transition Command
Target Value Simple Usingned8 1
State
Command
Name Description
0 Inactive No action
128 Adjust
Piezo /
CDG This service is used for activating the adjustment of
the piezo sensor to the Capacitance diaphragm sen-
sor.
The Transition Command Target Value can have the
following values:
0
⇒ executes a User ATM adjust
1
⇒ releases User ATM adjust
3.3.4 Atmosphere Sensor
Transducer Block (Piezo
Sensor) / SLOT 1 /
Instance 4
3.3.4.1 Block Type
3.3.4.2 Atmosphere Sensor Block
State Command
