This parameter indicates the detectable warnings occurring in connection with the
Pirani measuring part. The present implementation allows detection of one warning.
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Byte 0 0 0 0 0 0 0 0 0
Byte 1 0 0 0 0 0 0 Electronics Warning 0
The Sensor Warning bits defined here are copied into the Device Block ID 28 in the
"Device Exception Detail Warning" range of the Pirani measuring part.
ID Name Structure Data type Bytes Access Store Initial Value
14 Hot Cathode
Block State
Command Rec 1 1_W
2_W FALSE
101 Block Type Simple Octet
string 4 2_R 16
102 Status
Extension
Simple UINT8 1 1_R
2_R V 0
103 Sensor
Alarm
Struct Array of
2 bytes 2 1_R
2_R V 0
104 Sensor
Warning
Struct Array of
2 bytes 2 1_R
2_R V 0
105 Emission
Status
Simple Boolean 1 1_R/W
2_R/W V 0
106 Emission
Current
Simple FLOAT 4 1_R/W
2_R/W NV
109 Degas
Status
Simple Boolean 1 1_R
2_R V
201 Emission
User Mode
State
Simple Boolean 1 1_R
2_R V 0
According to the table in Appendix A, the Block Type ID has the value "16".
This parameter indicates that the overrange or underrange of the Hot Cathode Ion
Gauge instance is exceeded.
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
0 0 0 0 0 Underrange
Exceeded
Overrange
Exceeded
Reading
Invalid
If the instance is operated in its overrange or underrange, the corresponding bit
and additionally the bit "Reading Invalid" is set.
If an error occurs, the bit "Reading Invalid" as well as the corresponding error bits
in Device Block (ID 26, 27, 28 Device Block) are set.
This parameter indicates the detectable errors occurring in connection with the BA
measuring part. The present implementation allows detection of one error.
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Byte 0 0 0 0 0 0 0 0 0
Byte 1 0 0 0 0 0 0 Electronics Failure 1) 0
1)
Electronics Failure includes a sensor error.
The Sensor Alarm bits defined here are copied into the Device Block ID 27 in the
"Device Exception Detail Alarm" range of the BA measuring part.
3.3.2.4 Sensor Warning
3.3.3 Hot Cathode Ion Gauge
Transducer Block /
SLOT 1 / Instance 2
3.3.3.1 Block Type
3.3.3.2 Status Extension
3.3.3.3 Sensor Alarm
