INFICON BCG450-SP ATM to Ultra-High Vacuum Triple Gauge (Profibus) - Manual (Page 29)

tira41e1 (2005-06) BCG450SPv1.cp
29
Safe State Coding PV behavior
Zero 0 The Process Value (measured value ID 19) is set
to 0.
Full Scale 1 The Process Value (measured value ID 19) is set
to the full scale value (ID 24).
Hold Last Value 2 The Process Value is set to the last valid value
obtained in the EXECUTING status.
Use Safe Value 3 The Process Value (measured value ID 19) is set
to the Safe Value (ID 40).
The Safe Value is the value output with the Process Value Parameter (ID 19) when
an error occurs or the gauge goes to the NOT EXECUTING status. If this value is
set to zero, it will remain on zero when the data unit is changed.
Overrange is the highest valid measured value at which Reading Valid is still
on "1".
Pressure unit Overrange
COUNTS 21602
Torr 1.5×10
-2
mTorr (Micron) 15
mbar 2×10
-2
Pascal 2
Underrange is the lowest valid measured value at which Reading Valid is still
on "1".
Pressure unit Underrange
COUNTS 6397.95
Torr 3.7503×10
-10
mTorr (Micron) 3.7503×10
-7
mbar 5.0×10
-10
Pascal 5.0×10 -8
3.2.3.8 Safe Value
3.2.3.9 Overrange
3.2.3.10 Underrange
