The following table lists the services and parameters integrated in the Device Block
(
→ Appendix A for abbreviations).
ID Name Structure Data type Bytes Access Value Store
15 Device Block State Simple Unsigned8 1 1_R/W
2_R/W
16 Block Type Simple Octet string 4 1/2_R 1 N
17 Device Type Simple Visible string 8 1/2_R CG N
18 Standard Revision Level Simple Visible string 9 1/2_R E54-0997 N
19 Device Manufacturer
Identifier Simple Visible string 20 1/2_R INFICON AG N
20 Manufacturer
Model Number Simple Visible string 20 1/2_R e.g.
353-554 N
21 Software or Firmware
Revision Level Simple Visible string 8 1/2_R e.g. 1.01 N
22 Hardware Revision Level Simple Visible string 8 1/2_R e.g. 1.0 N
23 Serial Number Simple Visible string 30 1/2_R e.g. 100 N
24 Device Configuration Simple Visible string 50 1/2_R e.g.
BCG450-SP N
25 Device State Simple Unsigned8 1 1/2_R V
26 Exception Status Simple Unsigned8 1 0_XI
1/2_R V
27 Exception Detail Alarm Record → below - 1/2_R V
28 Exception Detail
Warning Record → below - 1/2_R V
204 Common Exception
Detail Alarm 0
Simple UINT8 1 1/2_R V
205 Device Exception Detail
Alarm 0 … 3
Struct Array of
4 bytes 4 1/2_R V
206 Device Exception Detail
Alarm 4 … 5
Struct Array of
2 bytes 2 1/2_R V
207 Manufacturer Exception
Detail Alarm 0
Simple UINT8 1 1/2 _R V
208 Common Exception
Detail Warning 0
Simple UINT8 1 1/2 _R V
209 Device Exception Detail
Warning 0 … 3
Struct Array of
4 bytes 4 1/2 _R V
210 Device Exception Detail
Warning 4 … 6
Struct Array of 3
bytes 3 1/2_R V
211 Manufacturer Exception
Detail Warning 0
Simple UINT8 1 1/2_R V
3.1 Device Block
