Bit
Device Exception Detail 4
Referring to Pirani
Bit
Device Exception Detail 5
Referring to BA
0 0 0 0
1 Electronics/sensor warning
Pirani
1 0
2 0 2 0
3 0 3 0
4 0 4 0
5 0 5 0
6 0 6 0
7 0 7 0
This byte is a copy of Sensor
Warning byte 1 of the Heat Transfer
Vacuum Gauge Transducer Block.
This byte is a copy of Sensor
Warning byte 0 of the Hot Cathode
Ion Gauge Transducer Block.
Bit
Device Exception Detail 6
Referring to BA
0 0
1 Electronics/sensor warning
2 0
3 Pressure too high for degas
4 0
5 0
6 0
7 0
This byte is a copy of Sensor
Warning byte 1 of the Hot Cathode
Ion Gauge Transducer Block.
Bit Manufacturer Exception Detail Warning
0 0
1 Relay A set if atmospheric pressure is reached.
2 Relay B set if atmosphere pressure is reached.
3 0
4 0
5 0
6 0
7 0
The following parameters are copies of the ID 27 and ID 28. They are
used only if you want to access these parameters by the parameter
channel.
This parameter corresponds to the Common Exception Detail Alarm of the
Exception Detail Alarm (ID 27).
This parameter corresponds to the Device Exception Detail Alarm Byte 0 … 3 of
the Exception Detail Alarm (ID 27).
This parameter corresponds to the Device Exception Detail Alarm Byte 4 … 5 of
the Exception Detail Alarm (ID 27).
Manufacturer Exception
Detail Warning
3.1.1.13 Copy Common Exception
Detail Alarm 0
ID 204
3.1.1.14 Copy Device Exception
Detail Alarm 0 … 3
ID 205
3.1.1.15 Copy Device Exception
Detail Alarm 4 … 5
ID 206
