INFICON BCG450-SD ATM to Ultra-High Vacuum Triple Gauge (DeviceNet) User Manual
Page 6
6
tira40e1 (2005-04) BCG450SDv1.cp
Position
Function
8
Potentiometer for Setpoint A threshold
9
Potentiometer for Setpoint B threshold
10
Special Calibration service / do not use
Device State
LED State
Description
Power Off
dark
No power applied to device
Device Self-Test
flashing
green/red
Device is in self-test
Device Operational
green
Device is operating normally.
Unrecoverable Fault
red
Device has detected an unrecoverable fault
Recoverable Fault
flashing red
Device has detected a recoverable fault,
e.g. missing DeviceNet power supply
1.4 Side View of the
BCG450-SD
1.5 Indicators and Switches
1.5.1 Module Status LED
