INFICON T3000 Thermal Power Supply - Manual (Page 9)

T3000 Thermal Power Supply instruments
Introduction – Description
of Equipment Page 1 - 2 Section 1
although it contains both DC and harmonics of line frequency. Therefore, the heating value
in the load (the resistive deposition source) is the same whether the current is sine wave,
rectified sine wave or a DC voltage all of equal RMS value.
The rectified line frequency was chosen as the output format because it offers an inherent
unity power factor characteristic for the power supply. This comes about because power is
being delivered to the resistive load throughout the 60-Hertz cycle of line frequency. Since
conversion from line to output is performed at 250 kHz, there is insignificant phase shift
introduced at the 60-Hertz line frequency. The net result is input line current that is, ideally,
sinusoidal and essentially in-phase with the line voltage. This is the condition for near unity
power factor.
1.3 Technical
Characteristics
Table 1-1 Specifications
Output Power 3000 Watts
Parallel Output 5 Volts @ 600 Amps RMS
Series Output 10 Volts @ 300 Amps RMS
Input Voltage Range 180-264 VAC, Single Phase
Input Freq. Range 47 Hz to 63 Hz
Input Current 18 Amps @ 220 VAC
Efficiency 80% Full Load
Power Factor >0.99 @ Full Load (TBD)
Total Harmonics < 5% @ Full Load (TBD)
Input Control 0 to +10VDC Required For Controlling Output Current
Response Time <100ms 250A to 500A Step Parallel Output
1
Current Monitor 1 VDC = 100 Amps RMS For Parallel & 50 Amps For Series
Voltage Monitor 1 VDC = 1.5 Volt RMS Across Output Terminals
Protection Over Temperature Shutdown
Size 11.4 in. H x 5.25 in. W x 12.9 in. D
Power Density 4 Watts per cubic inch
Weight 28 Pounds
Ambient Range 0
o
C to +50
o
C at full load
Cooling Forced air, two internal fans
EMI Designed to meet Conducted and Radiated EN55022
Safety Designed to meet EN60950
Output Connectors Flat bus bars with ¼” Bolt Hole for Lug Attachment
AC Input Wiring 2-Wire plus Ground with 8 – 32 lugs
I/O Connector 15-pin Dsub for control, monitoring and status signals
Power ON Indicator Green LED: Flashing=Input Power ON, Steady=Output ON
Over Temperature Red LED: Steady=Over Temp, Flashing=Ready for Reset
Open Load Red LED: Steady=Open Load
Compatibility Sycon Controller RS3000 &/or Rate Deposition Controllers
Footnote1; Response time is load dependent with lower resistance loads exhibiting faster response.
