1 7
MAINTENANCE
In general, just keeping your INCRA JIG clean is all you need to do to keep the tool in tip top shape. Occasionally, remove the
carriage from the base and brush or blow out any sawdust or debris that may have accumulated on the base and the UHMW
guide bearing strips. Use a toothbrush to clean the teeth on the INCRA racks on both the carriage clamp and on the carriage.
SYMPTOM PROBABLE CAUSE SOLUTION
Micro adjusting knob will not Carriage clamp is not "unlocked" Carriage clamp must be pushed down to the "unlock"
rotate or is difficult to rotate. position and the micro adjust lever must be pressed
down to place the jig in the micro adjust mode. See
page 7, Steps 1- 4.
Jig is micro adjusted to end of the Micro adjust back to mid-range position as indicated by
forward travel range. the micro adjust range scale. (Turn knob counter-
clockwise until "0" on the scale is aligned with the left
end of the micro adjusting knob.)
Micro adjusting knob rotates Micro adjust lever not engaged. After "unlocking" the carriage clamp the micro adjust
but no movement of the lever must be pushed down to place the jig in micro
carriage or fence. adjust mode. See page 7, Steps 1- 4.
Jig micro adjusted to end of Micro adjust jig forward to mid-range as indicated by
backward travel range. the micro adjust range scale. (Turn knob clockwise
until "0" on the range scale is aligned with the left end
of the micro adjust knob.
After placing jig in micro Micro adjust range scale not Realign micro adjust range scale. See page 18.
adjust mode, the micro properly aligned.
adjusting knob will not turn
even though the range scale
indicates travel range
available.
Carriage clamp squeaks Carriage clamp pivot pin needs Remove the carriage from the base, then remove the
when clamping or lubrication (6) phillips head wood screws that secure the ULTRA
unclamping base to your plywood subbase. Turn the ULTRA's
base upside down and you'll see where the carriage
clamp pivot pin passes through the clamp handle.
Apply a thin coat of light grease to the pivot pin using a
small cotton swab then remount the ULTRA base to
your plywood. See page 4, Fig. 1.
1 /
8
" thick carriage clamp pad Apply a thin coat of light grease to the carriage
needs lubrication. clamp pad.
