General Machine Products 70400 Apollo Cable Lasher - Manual (Page 22)

22
Apollo Lasher
REAR STRAND
RELEASE KNOB
Fig. 32, Rear View
VERTICAL
ROLLER ASSY
LOWER SHAFT
SUPPORT ASSY
EXIT ROLLER (LH)
EXIT ROLLER (RH)
LOWER REAR
ROLLER ASSY
REAR GUIDE
ROLLER
REEL COVER
Fig. 31, Side View
LOWER
TENSION
ROLLER
SHAFT
