10
Apollo Lasher
Figure 13
Figure 15
Figure 14
Figure 16
9. Feed the wire into the drive
wheel from the rearward di-
rection so the wire moves
around the drive wheel to-
ward the front of the lasher.
10. Continue feeding wire until it
exits the drive wheel. The
wire exiting the drive wheel
must be below the wire enter-
ing the drive wheel.
11. Pull up on the handle to dis-
engage the drive wheel and
feed wire into the exit rollers
on the end of the machine.
