INSTALLATION INSTRUCTIONS
Product
Revision
Form
If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868
Printing Spec:
PS-001
SCANNER HOLDER ASSEMBLY
7160-0499
The following instruction sheet is for mounting the part numbers listed
above. These mounts are designed to attach to the pillars of various
fork trucks.
The assembly attaches to the overhead guard leg on the fork truck. It can fit a
rectangular pillar from 1 1/2" to 5" wide. The mounts are held in place with
3/8" dia. carriage bolts.
Attach the Holder assembly to the pillar using the 3/8" carriage bolts and
back plate.
The assembly should be positioned so the top surface of the mount is relatively
level. (See figures 1 & 2).
1 of 3
