CRADLE, DELL E-64XX & E-64XX ATG

INSTALLATION INSTRUCTIONS

Product

Revision

Form

If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868

7160-0201

Rev. D

INST-438

Product Mounting Disclaimer
Gamber-Johnson is not liable under any theory of contract or tort law for any loss, damage, personal injury, special, incidental or consequential damages for personal injury or other damage
of any nature arising directly or indirectly as a result of the improper installation or use of its products in vehicle or any other application. In order to safely install and use Gamber-Johnson
products full consideration of vehicle occupants, vehicle systems (i.e., the location of fuel lines, brakes lines, electrical, drive train or other systems), air-bags and other safety equipment is
required. Gamber-Johnson specifically disclaims any responsibility for the improper use or installation of its products not consistent with the original vehicle manufactures specifications
and recommendations, Gamber-Johnson product instruction sheets, or workmanship standards as endorsed through the Gamber-Johnson Certified Installer Program. The OEM port
replicators used in docking cradles are not warrantied by Gamber-Johnson.

Page

© copyright 2011 Gamber-Johnson, LLC

4 / 5

Accessories (see Figure 4)

Tools Needed

9/64" Hex-Key Wrench

11/21" Box Wrench

#2 Philips Screw driver

Screen Support

1. Secure the Screen Support to the left side of the Cradle using (2) #8-32 x .50

Socket Head Cap Screws and (2) #8 Flat Washers with a 9/64 Hex-Key Wrench.

2. Adjust the position of the Screen Support against the Computer Screen by loosening

the (2) #8-32 Socket Head Cap Screws and (2) #8-32 Nylok Nuts

Light

1. Secure the light to the right side of the Cradle using (2) #8-32 x .50 Socket Head

Cap Screws and (2) #8 Flat Washers with a 9/64" Hex-Key Wrench.

Isolator Plate

1. Secure (4) isolators using (8) #6-32 x .25 Pan Head Screws.

2. Secure the isolator p;ate using (4) #8-32 x .38 Pan Head Screws.
