CF-31 DOCKING STATION FEATURE IDENTIFICATION
Alignment Pin
Interlock Pin
Front Retainer
Docking Connector
External Antenna
Connectors
Alignment Pin
USB Port
Docking Indicator
LED
Docking Handle
Push Button / Auto Lock
Wireless Antenna Switch
(WWAN Antenna)
Serial 2
Serial 1
Video Connection
External Microphone
External Speaker
or Headphones
Ethernet 2
Ethernet 1
USB Ports
Cable Restraint
Bracket
WLAN/GPS Antenna
Connector
WWAN Antenna
Connector
DC IN
Pg 2
Power Supply, Cables &Covers
Internal Power Models Only
