REPLACMENT INSTRUCTIONS
Roseville, MN
Ph: 1-800-444-2373
Fax: 651-645-7390
www.fastestinc.com
WP111 10/7/2010
CAP CONNECTOR
CONNECTOR
CAP CROSS-SECTION CONNECTOR CROSS-SECTION
CONNECTOR MAINTENANCE:
•
A daily, weekly and periodic inspection of the connector by competent
person is recommended.
•
User must establish a regular interval for maintenance as determined by
the user media and operational environment.
•
Inspection should include damage to the body missing or loose
components, leak tightness, ease of operation, sufficient lubrication,
wear, dirt accumulation and damage.
•
Inspect threads for wear.
•
Use only original FasTest spare parts that are designed for the
application and are subject to strict quality control. See Warranty.
•
Lubricate on regular intervals under normal operating conditions.
Lubrication should be compatible with user application.
FasTest, Inc. Product Warranty
FasTest, Inc. warrants its products against defects of workmanship and/or material for 12 months from
the date of the sale by FasTest, Inc. This warranty is void if the product is misused, tampered with or
used in a manner that is not in accordance with FasTest, Inc. recommendations and/or instructions.
FasTest, Inc. is not liable for consequential or other damages including, but not limited to, loss, damage,
personal injury, or any other expense directly or indirectly arising from the use of or inability to use its
products either separately or in combination with other products. ALL OTHER WARRANTIES
EXPRESSED OR IMPLIED, WHETHER ORAL OR WRITTEN, INCLUDING BUT NOT LIMITED TO
WARRANTIES OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE
EXPRESSLY EXCLUDED.
Remedy under this warranty is limited to replacement of the product or an account credit in the amount
of the original selling price, at the option on FasTest, Inc. All allegedly defective products must be
returned prepaid transportation to FasTest, Inc. along with information describing the products
performance, unless disposition in the field is authorized in writing by FasTest, Inc.
METR Internal Seal Replacement Instructions.
Description: Internal Seal and Back-Up Ring Replacement
Instructions for NPT, JIC and SAE O-Ring Boss Connectors.
Please thoroughly read the following steps on properly replacing seals and
back-up rings on MET Connectors.
1. MET Cap Connector Internal Seal Replacement.
2. MET Connector Internal Seal Replacement.
NOTE: FACE SEALS SOLD SEPARATELY
WARNING: If instructions are not clear or components are missing, contact
factory before using connector.
