Manual EKS Light and Light FSA
1 General notes
1.1 Use of the manual
This manual describes the technical features and the function of the EKS Light read stations listed below:
With the compact version, the Electronic-Key adapter and the evaluation and interface electronics for data
transmission are accommodated completely in one housing.
 Compact Electronic-Key adapter EKS-A-IPB-G01-ST05/02 (order no. 111 230); device supports only
operating state 0
 Compact Electronic-Key adapter EKS-A-IPL-G01-ST05/02 (order no. 109 820); device supports all
operating states
 Compact Electronic-Key adapter EKS-A-IPLA-G01-ST05/04 (order no. 112 207); device supports all
operating states; version FSA (For Safety Applications)
With the modular version, the Electronic-Key adapter and the interface adapter with the evaluation and interface
electronics for data transmission are accommodated in two separate housings:
 Modular Electronic-Key adapter EKS-A-SFH... in combination with modular interface adapter
EKS-A-APB-G08 (order no. 113 665); device supports only operating state 0
 Modular Electronic-Key adapter EKS-A-SFH... in combination with modular interface adapter
EKS-A-APR-G08 (order no. 113 647); device supports all operating states
 Modular Electronic-Key adapter EKS-A-SFH... in combination with modular interface adapter
EKS-A-APRA-G08 (order no. 113 645); device supports all operating states; version FSA (For Safety
A
pplications)
1.1.1 Explanation of symbols
The following symbols are used in this manual to identify important instructions and useful information.
Danger!
Identifies an immediate hazard. If not avoided, the consequence will be fatality or very serious injuries.
Warning!
Identifies a possible hazard. If not avoided, the consequence may be fatality or very serious injuries.
Caution!
Identifies a possible hazard. If not avoided, minor injuries or damage may result.
Attention!
Risk of damage to material or machine or degradation of function.
Information!
Important information is provided to the user here.
