Manual EKS Light and Light FSA

4.4.2 DIP switch settings in operating state 1

Bit
no.

15

14

13 12

11 10

9 8 7 6 5 4 3 2 1 0

MSB

LSB

1 bit

1 bit

4 bits

10 bits

ON

OFF

S1.1

S1.2

S1.3

S1.4

S1.5

S1.6

S2.1

S2.2

S2.3

S2.4

S2.5

S2.6

S2.7

S2.8

S2.9

S2.10

Even

parity

No

funct.

Operating State OS

Value: 1

dec

Access Code AC

Example: Access to S2.9

4.4.3 Operating state (OS) (bit nos. 10 to 13)

The operating state is set in binary form using switches S1.3 to S1.6. The value is always 1 for operating state
1; only the switch S1.6 is therefore set to ON.

4.4.4 Access code (AC) (bit nos. 0 to 9)

The access code is set in binary form using switches S2.1 to S2.10. The switches set to ON are evaluated. An
access code therefore results from the bit pattern of the set bits (switch S2.1 and/or S2.2 and/or S2.3 ... S.10 to
ON).

4.4.5 Data on the Electronic-Key in operating state 1

In an EKS Light data block with a length of 6 bytes, the following elements are stored on the Electronic-Key from
Electronic-Key byte no. 110:

 the EKS operating state (OS) with the value 1 (input via EKM).
 an access code (AC) from the bit pattern of the set bits (click on positions S2.1 and/or S2.2 and/or S2.3 ...

S.10 on the input mask) (input via EKM).

 an access level (AL) with the value 0 to 15 (input via EKM)
 a cyclic redundancy check (CRC) (automatically generated via EKM)
 a serial number (fix coded)

Block byte no.:

0

1

Key

byte

no.:

96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111

Value [dec]:

Value [hex]:

Function:

freely available for further EKS application

used...

Block byte no.:

2

3

4

5

Key byte no.:

112 113 114 115 116 117 118 119 120 121 122 123

Value [dec]:

Value

[hex]:

01 1A 1E F1 02 00 10 32

Function:

...for operating state 1

Serial number (sample values)

Page 20/40

Subject to technical modifications

110845-04-03/12
