Operating Instructions Safety System CES-A-UBA-01/CES-A-UBA-01B
30
Read head CES-A-LMN-SC
Ì
Cylindrical design M12
Ì
M8 plug connector (snap-action and screw terminals)
Ì
In combination with CES-A-BMB actuator
Dimension drawing
Note
The read head is allowed to be installed as a maximum up to the clear zone (area
of the active face without metal housing).
Typical operating distance
With evaluation unit CES-A-UBA-01 and actuator CES-A-BMB
With evaluation unit CES-A-UBA-01B and actuator CES-A-BMB
Note
A minimum distance of s = 1.2 mm must be maintained.
Approvals
17
5
32 19,
7
s
m
35
4
8
30
M1
2
x1
M8
x1
37
1)
1)
Reading distance
Centr
e of
fset
connected
Active face
1) Clear zone (area of the active face without metal housing)
-4 -2 -3 -1 1 3 2 4 0
1
2
3
4
Centre offset m [mm]
Distance s [mm]
OFF
ON
Actuator
Read
head
s
m
Hysteresis
Switch-on
distance
ON
OFF
Hysteresis
Distance s S ao
Output state
Switch-off
distance
OFF
-4 -6 -2 0
S ao
-8 2 8 6 4
2
4
6
8
s
m
Mittenversatz m [mm]
Abstand s [mm]
AUS
EIN
Einschalt-
abstand
EIN
AUS
Hysterese
Abstand s
Ausgangszustand
Abschalt-
abstand
AUS
Betätiger
Lese-
kopf
unzulässiger Bereich unzulässiger Bereich
Hysterese
