Operating Instructions Safety System CES-A-UBA-01/CES-A-UBA-01B
13
Connection example
CES-A-UBA-... (example based on CES-A-UBA-01B)
Important!
To achieve category 3 according to EN ISO 13849-1, it is necessary to monitor
the downstream contactors (not shown here).
This example shows only an excerpt that is relevant for connection of the CES
system. The example illustrated here does not show complete system planning.
The user is responsible for safe integration in the overall system.
24 VDC
GND
-F1
CES-A-UBA-01B
096961
0V
TST
-F2
24V
OUT ERR
-V1
SH1
GND
-K1
Read-
head
H11
Trans-
ponder
23
H12
24
-V2
EUCHNER
13 14
-K2
L1
-K2
13
14
-K1
13
14
M
3
~
-M1
L2
23
24
23
24
L3
33
34
33
34
