Read head CES-A-LNA...
Ì
Cube-shaped design 42 x 25 mm
Ì
Hard-wired cable
Ì
In combination with CES-A-BBA actuator
Dimension drawing
Typical operating distance
With evaluation unit CES-A-UBA-01 and actuator CES-A-BBA
With evaluation unit CES-A-UBA-01B and actuator CES-A-BBA
Note
For a side approach direction for the actuator and read head, a minimum distance
of s = 3 mm must be maintained so that the operating distance of the side lobes
is not entered.
