6 Source Four XT HID Zoom User Manual
Installation
Install on a suitable, rigid permanent base with secured bolts. This can include poured concrete
pads, factory-supplied pole-top and wall-mount brackets, and other attachments which meet the
published weight and wind-load requirements for the fixture. Use the full-sized template that is
included in the installation instructions or download the template at www.etcconnect.com.
Electrical
The fixture is completely pre-wired at the factory; there is no need for entry into the ballast housing.
Source Four XT HID
Weight Wind Load
XT HID 15-30 39 lbs. exclusive of accessories, color filters, and patterns. 1.4 square feet of effective projected area (EPA)
XT HID 25-50 34.5 lbs. exclusive of accessories, color filters, and patterns. 1.15 square feet of effective projected area (EPA)
W A R N I N G : Do not use this fixture with a damaged power lead. If the power lead
(cordset) is damaged, it must be replaced. Failure to follow this warning can
result in serious injury or death.
W A R N I N G : All third-party mounting hardware should be corrosion-resistant and
designed for use where installed.
C A U T I O N : The fixture must be grounded and wired in accordance with national, state and
local electrical codes. Failure to do may result in serious personal injury.
