2 Source Four XT HID Zoom User Manual
Applications
Lamp and Ballast Information
HID Lamps
Ballast
• Acceptable voltage is either 120V or 220V - 277V (±10%) 50/60 Hz only, depending
on the model purchased.
• 120V (Nominal) Ballast:
• 120V ±10%, 60Hz
• 1.5 Amps operating current
• 220V, 230V (50Hz), 240V, 277V (Nominal) Ballast:
• 277V ±10%, 60Hz
• 220V, 230V, 240V ±10%, 50Hz/60Hz
• 0.61 Amps operating current at 277V
• 0.69 Amps operating current at 230V
• 150 watt, high-power factor, fully encapsulated electronic ballast.
• Tilt-down reflector housing for lamp change, without disturbing focus.
• Houses of worship • Retail store logos and patterns
• Theme parks • Outdoor performance venues (non-dimming)
• Museums • Public sculptures
• Outdoor signage
C A U T I O N : Do not use lamps other than the HID in Source Four XT fixtures. Use of lamps
other than HID will void UL/cUL safety compliance and your warranty.
C A U T I O N : This fixture must be grounded.
C A U T I O N : The fixture is sold for either 120V or 220V, 230V (50Hz), 240V, 277V to match the
power supply. Verify that the lamp and ballast voltage requirements matches your
power supply. Connecting the fixture to the wrong voltage voids the
warranty.
Ceramic Metal Halide
Part
number
Lamp code Watts Base Bulb
Initial
Lumens
Color temp. CRI
Average rated
life
RT157 CDM150/T6/830
150 G12 T6
14,000 3000°K 85 12,000 hours
RT158 CDM150/T6/942 12,700 4200°K 96 12,000 hours
C A U T I O N : Source Four HID fixtures are not dimmable. Dimming will damage the ballast
and void your warranty.
