2. Cable Kits
Several Cable Kits can be purchased from Elmo. Each contain a set of 8 cables. The -5 suffix
on the kits and on the cables (CBL-DFDBK-5 for example) indicate that the cables are 5m
long. Cables and kits without that suffix are 2m long (except for CBL-RJ45CAN2 which is
20cm long). Customers may purchase cables in kits, or individually in multiples of 10
each. The contents of the kits are listed below:
Cable Application
Cable Part. No. CBL-CORKIT01
-CORKIT01-5
CBL-CORKIT02
-CORKIT02-5
RS-232 Communications CBL-RJ452321 -5
CAN Communications CBL-RJ45CAN1 -5
CAN –CAN Daisy -Chain CBL-RJ45CAN2 -5
Analog Inputs CBL-A001 -5
Digital Inputs CBL-D002 -5
Digital Outputs CBL-D001 -5
Main Feedback (gnrl-purpose) CBL-DFDBK -5
Auxiliary Feedback CBL-DAUX -5
Auxiliary Power CBL-CEL24 -5
Power (general-purpose) CBL-MTRPWR -5
Motor (SAR, SA, SB, SC) CBL-MTRPWR1 -5
Motor (for SE) CBL-MTRPWR2 -5
Cornet Cable Kits
MAN-CBLKIT-COR (Ver. 1.0)
3
