1.2 Cable Cross-Reference
Cable Application
Cable Part. No. No. of
Pins
Label on
Cornet pg
RS-232 Communications
CBL-RJ452321 -5
8 COM.1 4
CAN Communications
CBL-RJ45CAN1 -5
8 5
CAN-CAN Daisy-Chain
CBL-RJ45CAN2 -5
8
COMM.2
6
Analog Inputs
CBL-A001 -5
ANALOG
INPUTS
7
Digital Inputs
CBL-D002 -5
COMMITTED
I/O
8
Digital Outputs
CBL-D001 -5
GENERAL I/O 9
Main Feedback (gnrl-purp.)
CBL-DFDBK -5
15 FEEDBACK A 10
Auxiliary Feedback
CBL-CELDAUX -5
15 FEEDBACK B 11
Auxiliary Power
CBL-CEL24 -5
2 +/- 12
Power (gnrl-purpose)
CBL-MTRPWR -5
4 13
Motor (for SAR, SA, SB, SC)
CBL-MTRPWR1 -5
4 13
Motor (for SE)
CBL-MTRPWR2 -5
4
PE/M1/M2/M3
13
