Gold Drum (RJ-45 Connectors) Installation Guide
MAN-G-DRUM(RJ45)IG-EC (Ver. 1.400)
||Technical Data| www.elmomc.com
9
Table of Contents
4.2.1. VL Logic Supply
Feature Details
Logic power supply Isolated DC source only
Logic supply input voltage 14 to 60 VDC
Logic supply input power ≤ 4 VA without external loading of 5V (Encoders)
≤ 6 VA with full external loading of 5V (Encoders)
The Gold Drum is available in a variety of options. There are multiple power rating options, two
different communications options, a variety of feedback selections and I/O configuration
possibilities.
4.2.2. Product Features
Main Feature Details Presence and No.
STO TTL √
PLC Source √
PLC Sink (is not fully certified, and
not recommended for new designs) √
Digital Input
Option TTL 6
PLC Source 6
PLC Sink 6
Digital Output
Option TTL 4
PLC Source 4
PLC Sink 4
Analog Input Differential ±10V 1
Feedback Standard Port A, B, & C √
Communication
Option USB √
EtherCAT √
CAN √
