||Physical Specifications
8
Chapter 4:
Technical Information
4.1. Physical Specifications
Feature
Units
All Types
Weight
g (oz)
700 g (24.7 oz)
Dimensions
mm (in)
134 x 95 x 72 (5.3" x 3.7" x 2.84")
Mounting method
Wall/Panel Mount
4.2. Technical Data
Feature
Un
it
s
*70/
48
*70/
60
*R
90/
60
50/
100
*R
75/
10
0
100/
100
35/
200
R60/
200
18/
400
Minimum supply voltage
VDC
11
14
14
46
92
Nominal supply voltage
VDC
42
50
85
170
340
Maximum supply voltage
VDC
48
59
95
195
390
Maximum continuous power
output
W
2700
3400
4300
4000
6000
8035
5600
9600
5600
Efficiency at rated power (at
nominal conditions)
%
> 97
Max output voltage
97% of DC bus voltage at f=22 kHz
V
L
Logic supply input voltage
VDC
14 to 60
V
L
Logic supply input power
VA
≤ 4 VA without external loading of 5V (Encoders)
≤ 6 VA with full external loading of 5V (Encoders)
Amplitude sinusoidal
continuous current
A
70
70
90
50
75
100
35
60
18
Sinusoidal continuous RMS
current limit (Ic)
A
50
50
63
35
53
71
25
42
12.7
Peak current limit
A
2 x Ic
2 x Ic No Peak
2 x Ic No Peak 2 x Ic
2 x Ic No Peak 2 x Ic
Table 1: Power Ratings
Note:
* Not recommended for new designs. The 100/100 covers those current/ voltage ratings with
higher efficiency
