Parts and Service Guide
Terreon ® Multi-Fount Washfountains
Bradley Corporation • 215-1447 Rev. F; EN 07-005A 9 1/30/2008
Corner Tri Quad
Item Part No. Description Qty Qty Qty
1 S08-340 Pushbutton Assy. (Includes Items 2 thru 4) 2 3 4
2 128-090 Pushbutton only 2 3 4
3 179-104 Guide for pushbutton 2 3 4
4 147-034 Shoulder Screw for pushbutton 2 3 4
5 182-110 Spacer 2 3 4
6 140-743 Bracket 2 3 4
7 110-115 Nut 2 3 4
- S65-168 Actuator Assy. (Includes items 9 thru 14) 2 1 2
- S65-168A Actuator Assy. (Includes itmes 9 thru 15) — 2 2
9* 119-227A Piston 2 3 4
10* 125-099 U-Cup 2 3 4
11* 135-065 Spring 2 3 4
12* 118-279 Actuator Body 2 3 4
13* 198-010 Duckbill Check 2 3 4
14 169-890 Tube Connector 1/8" straight 2 3 4
15† 269-1186 Fitting Adj J — 2 2
16 160-165 Screw 4 6 8
17 R68-600008-R Tubing 1/8" OD, Red (specify length in feet) — — —
17 R68-600008-G Tubing 1/8" OD, Green (specify length in feet) — — —
17 R68-600008-B Tubing 1/8" OD, Black (specify length in feet) — — —
17 R68-600008-Y Tubing 1/8" OD, Yellow (specify length in feet) — — —
18 115-131 Sprayhead 2 3 4
19 176-119 Threaded Rod 4 6 8
20 269-1190 Window Hole Plug 4 6 8
21 140-748 Backplate 2 3 4
22 161-026 Nut 4 6 8
23 142-002BS Lockwasher 4 6 8
24 269-871 Fitting Straight (front sprayhead) — 1 2
25 269-628 Fitting Swivel 90° (side sprayheads) 2 2 2
26 R68-600011-R Tubing 1/4" ID, Red (specify Length in feet) — — —
26 R68-600011-G Tubing 1/4" ID, Green (specify Length in feet) — — —
26 R68-600011-B Tubing 1/4" ID, Black (specify Length in feet) — — —
26 R68-600011-Y Tubing 1/4" ID, Yellow (specify Length in feet) — — —
27 130-023 Spanner Wrench 1 1 1
Parts List
* Repair Kit S65-168 (incl. parts 9, 10, 11, 12, 13)
*, † Repair Kit S65-168A (incl. parts 9, 10, 11, 12, 13, 15)
