24
Figure 23—Clip Positioning for Q4004 Mounting Racks
(A)
(B)
(C)
1.48 (37.59)
(D)
A1475
ALL CONTROLLER CAGES REQUIRE
A MINIMUM OF 10.12 INCHES (257.1 MM)
DEPTH CLEARANCE
(E)
1
A1476
FIRE CONTROLLERS ARE APPROX. TWO INCHES
WIDE AND REQUIRE TWO GUIDE RAILS FOR
INSERTION. PLACE THE RETAINING CLIP BETWEEN
RAILS TO FORM SETS, LEAVE A GAP BETWEEN SETS.
SET
SET
GAP
1
2
3
2
THE Q4004 CONTROLLER CAGE HAS BEEN MODIFIED
TO ACCOMMODATE EITHER FIRE OR GAS CONTROLLERS
OR ANY COMBINATION OF THE TWO.
BY FOLLOWING THE INSTRUCTIONS BELOW, THE CAGE
CAN BE SET UP TO ANY CONFIGURATION.
2
TO INSERT A BLANK PANEL, PLACE A CLIP IN
THE TOP BRACKET IN LINE WITH THE CLIP IN THE
BOTTOM BRACKET.
3
GAS CONTROLLERS ARE APPROX. ONE INCH WIDE
AND REQUIRE ONE RAIL FOR INSERTION. PLACE CLIPS
IN LINE WITH GUIDE RAILS, CAGES WILL ACCEPT AS
MANY GAS CONTROLLERS AS RAILS PROVIDED.
RACK
PART NUMBER
CONTROLLER
TYPE
005269-XXX
POSITIONS FOR:
HT:
DIM. (A)
DIM. (B)
DIM. (C)
DIM. (D)
DIM. (E)
WEIGHT
FIRE GAS
INCH MM
INCH MM
INCH MM
INCH MM
INCH MM
LB
KG
4U
–001
8
16
4U
19.00
482.6
18.30
464.8
17.36
440.9
4.00
101.6
6.97
177.1
9.3
4.2
4U
–002
6
12
4U
15.06
382.6
14.36
364.7
13.42
340.9
7.6
3.5
4U
–003
4
8
4U
11.13
282.6
10.43
264.9
9.49
241.1
5.9
2.7
4U
–004
3
6
4U
9.16
232.7
8.46
214.9
7.52
191.0
5.1
2.3
4U
–005
2
4
4U
7.19
182.7
6.49
164.9
5.55
141.0
4.2
1.9
4U
–006
1
2
4U
5.22
132.6
4.52
114.8
3.58
90.9
3.1
1.4
3U
–007
16
3U
19.00
482.6
18.30
464.8
17.36
440.9
2.25
57.15
5.22
132.6
9.3
4.2
3U
–008
12
3U
15.06
382.6
14.36
364.7
13.42
340.9
7.6
3.5
3U
–008
8
3U
11.13
282.6
10.43
264.9
9.49
241.1
5.9
2.7
3U
–010
6
3U
9.16
232.7
8.46
214.9
7.52
191.0
5.1
2.3
3U
–011
4
3U
7.19
182.7
6.49
164.9
5.55
141.0
4.2
1.9
3U
–012
2
3U
5.22
132.6
4.52
114.8
3.58
90.9
3.1
1.4
Figure 22—Dimensions of Q4004 Mounting Rack
