95-8532

1.4

17

Display

“YES EXT”

“YES CAL”

or

“NO EXT”

“NO CAL”

“4-20 CAL”

“NO”

“SET 4mA”

“CURRENT”

“SET 20mA”

“CURRENT”

“SET CAL”

“CURRENT”

function

Option to allow external reset button

to be used for calibration in addition

to or instead of Cal Magnet. When

“Yes” is selected, the external reset

input functions exactly like the Cal

Magnet.

Option to select a Current Loop

Output other than factory calibrated

4 to 20 ma.

Set the current output zero level.

Set the current output full scale

level.

Set the current output during

calibration and setup modes.

Description/action

• Press INCREASE or DECREASE to change the

setting.

• When the desired setting is displayed, press the

SETUP/ACCEPT button to program the setting

into the transmitter. Factory default setting

is for no - external reset button is not used for

calibration.

• Press the SETUP/ ACCEPT button to bypass the

4 to 20 ma calibration procedure and exit the

SETUP mode.

• Press DECREASE or INCREASE to change the

display to read “4-20 CAL” “YES.”

• Press the SETUP/ACCEPT button to program the

current loop.

• Press the INCREASE or DECREASE button to

change the zero level current output (indicated on

the dc current meter).

• When the desired output is indicated, press the

SETUP/ACCEPT button to program the setting

into the transmitter.

• Press the INCREASE or DECREASE button

to change the full scale current level output

(indicated on the dc current meter).

• When the desired output is indicated, press the

SETUP/ACCEPT button to program the setting

into the transmitter.

• Press the INCREASE or DECREASE button

to change the calibration current level output

(indicated on the dc current meter).

• When the desired output is indicated, press the

SETUP/ACCEPT button to program the setting

into the transmitter.

IMPORTANT

A dc current meter capable of measuring 4 to 20 ma must be connected to the current loop output for the
following three current loop adjustments. This can be accomplished by connecting a dc ammeter in series
with the load or by connecting a digital dc voltmeter across a known load resistance and calculating the
current flow using the formula: current (I) = voltage/load resistance.

Do not press INCREASE or DECREASE pushbuttons during Current Loop Cal without a current meter or
voltmeter connected to the current loop output as described above. Doing so will result in an uncalibrated
current loop.

Table 6—Infiniti Setup (Continued)
