Det-Tronics X3302 Multispectrum IR Flame Detector - Manual (Page 27)

25 95-8576 9.2
high Sensitivity
False Alarm Source
Distance
feet (m)
Fire Source
Distance
feet (m)
Average Response
Time (seconds)**
Sunlight, direct, unmodulated* — Hydrogen @ 100 SLPM 50 (15.2) 5
Sunlight, direct, modulated* — Hydrogen @ 100 SLPM 10 (3.0) 6
Sunlight, reflected, unmodulated* — Hydrogen @ 100 SLPM 50 (15.2) 3
Sunlight, reflected, modulated* — Hydrogen @ 100 SLPM 25 (7.6) 3
Arc welding, steady, #7014 15 (4.6) Hydrogen @ 100 SLPM 75 (22.9) 3
Arc welding, modulated, #7014 15 (4.6) Hydrogen @ 100 SLPM 52.5 (16) 3.5
70 w sodium vapor, unmodulated 8 (2.4) Hydrogen @ 100 SLPM 75 (22.9) 3.5
70 w sodium vapor, modulated 8 (2.4) Hydrogen @ 100 SLPM 75 (22.9) 2.5
250 w vapor lamp, unmodulated 8 (2.4) Hydrogen @ 100 SLPM 75 (22.9) 2.5
250 w vapor lamp, modulated 8 (2.4) Hydrogen @ 100 SLPM 52.5 (16) 2.5
300 w incandescent lamp, unmodulated 8 (2.4) Hydrogen @ 100 SLPM 75 (22.9) 3
300 w incandescent lamp, modulated 8 (2.4) Hydrogen @ 100 SLPM 45 (13.7) 2
500 w shielded quartz halogen lamp, unmodulated 10 (3.0) Hydrogen @ 100 SLPM 75 (22.9) 2.5
500 w shielded quartz halogen lamp, modulated 10 (3.0) Hydrogen @ 100 SLPM 26 (7.9) 1.5
1500 w electric radiant heater, unmodulated 8 (2.4) Hydrogen @ 100 SLPM 75 (22.9) 2.5
1500 w electric radiant heater, modulated 8 (2.4) Hydrogen @ 100 SLPM 30 (9.1) 5.5
Two 34 w fluorescent lamps, unmodulated 4 (1.2) Hydrogen @ 100 SLPM 75 (22.9) 3
Two 34 w fluorescent lamps, modulated 4 (1.2) Hydrogen @ 100 SLPM 75 (22.9) 2.5
* Outdoor test conditions.
** Add 2 seconds for EQP model.
Medium Sensitivity
False Alarm Source
Distance
feet (m)
Fire Source
Distance
feet (m)
Average Response
Time (seconds)**
Sunlight, direct, unmodulated* — Hydrogen @ 100 SLPM 50 (15.2) 6
Sunlight, direct, modulated* — Hydrogen @ 200 SLPM 10 (3.0) 4
Sunlight, reflected, unmodulated* — Hydrogen @ 100 SLPM 50 (15.2) 3
Sunlight, reflected, modulated* — Hydrogen @ 100 SLPM 25 (7.6) 4
Arc welding, steady, #7014 10 (3.0) Hydrogen @ 100 SLPM 50 (15.2) 3
Arc welding, modulated, #7014 10 (3.0) Hydrogen @ 100 SLPM 35 (10.7) 4
70 w sodium vapor, unmodulated 5 (1.5) Hydrogen @ 100 SLPM 50 (15.2) 2.5
70 w sodium vapor, modulated 5 (1.5) Hydrogen @ 100 SLPM 50 (15.2) 3
250 w vapor lamp, unmodulated 5 (1.5) Hydrogen @ 100 SLPM 50 (15.2) 3
250 w vapor lamp, modulated 5 (1.5) Hydrogen @ 100 SLPM 35 (10.7) 2
300 w incandescent lamp, unmodulated 5 (1.5) Hydrogen @ 100 SLPM 50 (15.2) 2
300 w incandescent lamp, modulated 5 (1.5) Hydrogen @ 100 SLPM 30 (9.1) 3
500 w shielded quartz halogen lamp, unmodulated 8 (2.4) Hydrogen @ 100 SLPM 50 (15.2) 2
500 w shielded quartz halogen lamp, modulated 8 (2.4) Hydrogen @ 100 SLPM 17.5 (5.3) 2
1500 w electric radiant heater, unmodulated 5 (1.5) Hydrogen @ 100 SLPM 50 (15.2) 4
1500 w electric radiant heater, modulated 5 (1.5) Hydrogen @ 100 SLPM 20 (6.1) 3
Two 34 w fluorescent lamps, unmodulated 3 (0.9) Hydrogen @ 100 SLPM 50 (15.2) 2.5
Two 34 w fluorescent lamps, modulated 3 (0.9) Hydrogen @ 100 SLPM 50 (15.2) 3
* Outdoor test conditions.
** Add 2 seconds for EQP model.
FM Approval and performance Report – Continued
