Det-Tronics X3302 Multispectrum IR Flame Detector User Manual

Page 18

95-8576

9.2

X3302 Reflector plates
X3302 models are supplied with either a black or a

stainless steel reflector plate. These plates are not

interchangeable. Order the replacement that matches

the reflector plate on your X3302 Flame Detector.

pERIODIC ChECkOUT pROCEDURE
In compliance with SIL 2, a checkout of the system using

the Mag

or Man

feature should be performed

regularly to ensure that the system is operating properly.

Refer to Table 1 in the X3302 Safety manual (95-8582) for

frequency of proof tests. To test the system, perform the

“Fire Alarm Test” as described in the “Startup Procedure”

section of this manual.

CLOCk BATTERy
The real time clock has a backup battery that will operate

the clock with no external power. Return the device to

the factory for battery replacement if needed.

NOTE

If the backup battery is depleted, there is no effect
on the operation of the flame detector, but the time
stamping of the data log may be affected.

FEATURES

• Unequaled false alarm rejection
• Responds to a fire in the presence of modulated

blackbody radiation (i.e. heaters, ovens, turbines)

without false alarm

• Microprocessor controlled heated optics for

increased resistance to moisture and ice

• Automatic, manual or magnetic

testing

• Easily replaceable

plate

• Fire, fault and auxiliary relays standard
• 0 to 20 mA isolated output (optional)
• Eagle Quantum Premier LON/SLC output (optional)
• HART communication (optional)
• FDT/DTM capable
• Multiple sensitivity levels
• A tri-color LED on the detector faceplate indicates

normal condition and notifies personnel of fire

alarm or fault conditions

• Operates under adverse weather conditions and in

dirty environments

• Mounting arm allows easy sighting
• Integral wiring compartment for ease of installation
• Explosion-proof/flame-proof detector housing.

Meets FM, CSA, ATEX Directive and CE certification

requirements

• Class A wiring per NFPA-72
• 5 year warranty
• RFI and EMC Directive compliant

Associated Manuals

List of X3302 related manuals:

TITLE

FORM NUMBER

Pulse

95-8578

EQP

95-8533

SIL 2 (Safety)

95-8582

HART Addendum

95-8613

Q9033 Mounting Arm

and Collar Attachment

95-8686

Inspector Monitor Software for

X-Series Flame Detectors

95-8581

Q1130 Flange Mount

95-8662
