1.5. Specifications
1.5.1. Model Numbering and Naming Conventions
Table 1 lists the model numbers and follows these conventions:
Model
Number
L
1
-
-
3
Position in
Number
1
2
3
4
5
6
7
8
Table 1. Model Number Key.
Position in
Model Number
Letter / Number
Letter Meaning
2
C
Model has a HEPA filter
2
L
Model does not have a HEPA filter
3
C
Model operates at 260°C
3
D
Model operates at 350°C
5 & 6
16
1.6 cubic foot model
5 & 6
51
5.1 cubic foot model
7 & 8
N
Model uses a nitrogen atmosphere
7 & 8
V
Model uses Viton
*
synthetic rubber (Silicone-
free option)
Example: LLD1-51NV-3
This 5.1 ft
3
model does not have a HEPA filter, operates at 350°C, uses nitrogen
and is silicone-free.
1.5.2.
Dimensions
Models
Chamber Size
inches (cm)
Capacity
ft
3
(liters)
Overall Size
inches (cm)
Maximum
number of
Shelves
W
D
H
W
D
H
LCC1-16-3
LCD1-16-3
LCC1-16N-3
LCD1-16N-3
15
(38)
14
(36)
14
(36)
1.6
(45)
32.5
(83)
35.5
(90)
20.75
(53)
5
LCC1-51-3
LCD1-51-3
LCC1-51N-3
LCD1-51N-3
23
(58)
20
(51)
20
(51)
5.1
(144)
40.5
(103)
42.5
(108)
27
(69)
8
*LLC & LLD models have same dimensions.
The LCC/LCD oven is not intended to process solvents or
other volatile or flammable materials. Oven exhaust is
intended for cooling purposes only.
*
