Despatch Stackable LCC/LCD - Manual (Page 10)

A BOUT T HIS M ANUAL Stackable LCC/LCD Oven Owner’s Manual
10 Version 26
Copyright © 2010 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
1.5.3. Capacities
Model LCC1-16-3 & LCD1-16-3
LCC1-16N-3 & LCD1-16N-3
LCC1-51-3 & LCD1-51-3
LCC1-51N-3 & LCD1-51N-3
Maximum Load (Lbs) 200 200
Maximum shelf load (Lbs) 50 25
Recirculating fan
(CFM) 240 435
(H.P.) 1/4 1/4
Net weight (Approximate)
(Lbs) 250 380
(KG) 114 172
Shipping weight (Approximate)
(Lbs) 350 525
(KG) 159 238
Exhaust capacity (forced
exhaust) (CFM)
35 73
Exhaust Outlet
(Inch) 1.88 x 2.88 1.88 x 2.88
(mm) (48.0 x 73.4) (48.0 x 73.4)
1.5.4. Power
If the line voltage for your LCC/LCD Oven varies more than 10% from the oven voltage
rating, electrical components such as relays and temperature controls may operate
erratically.
If the line voltage is lower than the oven voltage rating, heat-up time may be
significantly longer and motors may overload or run hot
If the line voltage is higher than the nameplate rating, motors may run hot and draw
excessive amperage
Model Volts * Amps Hertz Heater Phase KW Cord and Plug
LCC1-16-3
LCD1-16-3
240 14.8 50/60 1 3 None, hardwired
LCC1-16N-3
LCD1-16N-3
240 14.0 50/60 1 3 None, hardwired
LCC1-51-3
LCD1-51-3
240 27.7 50/60 1 6 None, hardwired
LCC1-51N-3
LCD1-51N-3
240 27.7 50/60 1 6 None, hardwired
*The LCC/LCD Oven is designed for 240 volts (see oven nameplate) will operate
satisfactorily on a minimum of 208 Volts, but will result in 25% reduced heater output. If
your power characteristic is lower, contact Despatch Industries.
