8. Appendices
8.1. HEPA Filter Pressure Reading Worksheet
A B C D E F
Date Comments Pressure
(inches of
water)
10
Pressure with:
150 SCFH (LCC1-
16); 200 SCFH
(LCC1-51) nitrogen
purge
11
Pressure with:
75 SCFH (LCC1-
16); 150 SCFH
(LCC1-51) nitrogen
maintain
9
Oven
Temperature
Typical
Values 2- 3” 1.5- 2” above value
in Column C
0.5- 1” above value
in Column C
60°C
Filter first
installed
10 With Purge and Maintain valves off for a nitrogen atmosphere oven. Cooling fan off for an air
atmosphere oven.
11
For a nitrogen atmosphere oven only.
