Dascom 2600 User Guide - Manual (Page 54)

Tally Dascom 2610
41
Width Width=13.6Inch
Width=8Inch
Width=13.2Inch Selects the line length in inches. With the
setting of 8 Inch, the printer operates like
a printer with a width of only 8 inches.
Eject Eject=Top
Eject=Front This is valid for single sheet mode only. It
controls the exit direction of the friction
sheet paper.
Barcode Off On With this function selected it is possible
to print different barcodes and LCP
(Large Character Printing).
Barmode Unsecured
Secured Allows printing of normal characters on
the left and right of the barcode.
FFmode Off On Specifies whether a form feed is to be
performed when the paper reaches the
top print line.
LeftMrg Wide: LeftMrg= 0 - 134/10”
Narrow: LeftMrg= 0 - 78/10”
The left print margin can be set to a fixed
value.
RightMrg Wide: RightMrg=2 - 136/10”
Narrow: RightMrg=2 - 80/10”
The right print margin can be set to a
fixed value.
