1.4 Parts description
1
Control Panel LED: The 2-line LED with 4 keys panel indicates the
operating status and allows simple settings of the printer;
LCD: A LCD display and two keys indicates the operating
status and allows simple settings of the printer.
2
Latch Sliding it down unfolds the cut sheet support.
3
Front Cover Unlocking the front cover unfolds the cut sheets support.
4
Power Switch Turns on and off the printer.
5
Hand Wheel Turn the knob to load or clear the paper. It should be
inserted the full way until you can hears some sort of
“Click”.
6
Paper Support At slanted position, it stacks cut sheets; at flat position, it
separates fanfold printouts from incoming forms.
7
Top Covers 1&2 Protect the internal parts and reduce the noise.
8
Head Gap Lever Adjusts the gap between the print head and various
form thickness.
9
Paper Path Lever Selects various paper sources.
10
Upper Friction Guides the form when cut sheets or fanfold forms are used.
11
Power Socket A power cord is plugged into the socket to supply the
power.
12
Interfaces The interface cable of the host computer is plugged into
one of the interfaces.
13
Mute Cover Latch You must open it before you open the top cover 1.
14
Print Head Utilizes 24 needles to strike on ink ribbon and paper.
15
Ribbon Cartridge Holds the ink ribbon fabric.
16
Tractors Holds and transports fanfold forms.
17
Paper Guides
Left/Right
Sliding the guides varies the form width and the left
margin on a cut sheet.
18
Cut Sheet Support A flat surface supports a sheet or multi-part form.
