Clarus Environmental Recirculating Media Filters - Manual (Page 8)

8
© Copyright 2011. All rights reserved.
Section 2: Clarus Environmental Recirculating Media Filter
Pump Discharge
SK2160A
Figure 4:
NOTE: System specific drawing provided with each system.
CLARUS 3" ORIFICE SHIELD
PLAN VIEW
6.5"
15"
17"
3/4" PVC PIPE
FROM PUMP TANK
13" 13"
SEE PIPE SEAL DETAIL
PROTECTIVE BLANKET UNDER
45 MIL EPDM RUBBER LINER
4" SLOTTED DRAIN PIPE
TO 80/20
PRESSURE FLOW
SPLITTER
PRESSURE TREATED
WOOD OR CONCRETE
(SUPPLIED BY OTHERS)
24" OF
FILTER MEDIA
11" MAXIMUM
OF 3/4" - 1 1/2" DIAMETER
PEA GRAVEL
ELEVATION VIEW
NATIVE SOIL MUST BE SMOOTHED,
RAKED, COMPACTED, AND LEVELED
THROUGHOUT IT'S LENGTH AND WIDTH
1.5"
8" MINIMUM
OF 3/4" - 1 1/2" DIAMETER
PEA GRAVEL
FILTER MEDIA
LINER
PIPE BOOT
ALL STAINLESS PIPE CLAMP FRAME
1 1/4" PVC PIPE
24"
6"
PIPE FROM PUMP MAY
NEED TO BE LARGER
2" PVC PIPE
J-BOX
PREWIRED CONDUIT
RISER & LID
TO 80/20
PRESSURE FLOW
SPLITTER
4" SLOTTED
DRAIN PIPE
CLARUS
PREWIRED CONDUIT
PATIO STONE OVER
CLEANOUT AND RISER
4" BERM (MINIMUM)
PATIO STONE
PROTECTIVE BARRIER
MALE NPT ADAPTER & CAP
4" X 3" PVC RISER
90° SWEEP ELBOW
CLEAN OUT RISER
42" MIN.
3"
