Modules
3.5G Module 7 - 19
7
4. Slide the SIMLOCK towards the hinge (in the direction of the arrow in Figure 7 -
14 ) in order to release the lock and lift it up.
5. Insert the USIM card as illustrated ( Figure 7 - 15 ) and close the SIMLOCK.
6. Lock the SIMLOCK by pushing it in the direction of the arrow ( Figure 7 - 15 ) until it
clicks into the lock position (replace the screw and cover as per Figure 7 - 13 ).
Figure 7 - 14
SIMLOCK Open
Figure 7 - 15
Insert SIM Card
and Lock
SIMLOCK
