Title
Installation & Operation
Rev 1.02A
Page 13
Quick service guide
TECHNICAL ISSUE CAUSE SOLUTION
Starts with doors open Faulty #1 micro switch (start/stop) Replace micro switch
Faulty door switch Replace switch
Faulty #1 micro switch (start/stop) Replace micro switch
Continues cycle Faulty start/fill switch Replace switch
Faulty door switch Replace door switch
Wash motor will not shut off Delimer switch in wrong position Switch to NORMAL position
Faulty motor contactor Replace contactor
Faulty # 6 micro switch Replace micro switch
Sanitizer pump does not run Delimer switch in wrong position Switch to NORMAL position
Faulty sanitizer pump motor Replace sani motor
Debris inside water solenoid valve Clean and replace diaphragm
Water solenoid leaking High water pressure on supply line Decrease water pressure
Faulty water solenoid valve Replace valve
Leaking drain ball Replace drain ball
Does not fill or hold water in tank
Faulty #4 micro switch (Fill) Replace micro switch
Debris inside water solenoid valve or
Faulty valve
Clean and replace diaphragm/valve
Worn internal vac. Brkr parts Replace or clean parts
Vacuum breaker leaks Faulty check valve
Replace check valve
Low incoming water pressure Increase water pressure
Only runs when start/fill switch is
depressed
Faulty #1 micro switch (start/stop) Replace micro switch
Faulty Door switch Replace door switch
Will not start/ nothing works Wall breaker tripped Reset breaker
Master on/off switch on machine turned
off, or faulty
Reset or replace master switch
Faulty #2 Micro switch (cycle reset) Replace micro switch
Runs, but none of the other functions
engage
Faulty ice cube relay (yellow relay) Replace relay
Faulty motor contactor Replace contactor
