12 DIGITAL VIDEO RECORDER
1) Camera Inputs : BNC input connectors ( 8 / 16CH)
2) Camera Outputs : LOOP-OUT connectors ( 8 / 16CH : BNC,)
3) Spot out connector : 8ch – 1 / 16ch – 3 SPOT OUT(Digital)
4) ALARM IN : 8/16 alarm/sensor inputs
5) RS-422 : For connecting to PTZ camera.
6) AC power socket : Universal voltage
7) 75 Ohm Termination (1~8/ 1~16)
8) AUDIO Input connectors : D-SUB to RCA ( 8CH : 1~8CH , 16CH : 1~8CH,9~16CH )
9) AUDIO Output (1) connectors: RCA
10) Composite Monitor Output : BNC standard composite video output connector.
11) VGA out connector.
12) eSATA connector: For connecting e-SATA compatible devices.
13) USB 2.0 connector: For connecting USB compatible devices.
14) ALARM OUT : 1~4
15) RJ-45 Ethernet Port (2): For connecting to remote PC via Ethernet network.
10/100/1000 BASE-T
16) RS-232C [D-SUB 9PIN] : For connecting to Debugging.
17) Power Fan
